COMPACT THREADING MACHINE FLARE.3C

MODEL FLARE.3C THREADING MACHINE
Heavy-duty performance with 1500W motor. Portable/ Light-weight design.
Easy transport and set-up.
Self-Contained Oil System with adjustable flow control.

the Macstroc FLARE.3C Threading Machine, a model characterized by heavy-duty performance driven by a potent 1500W motor. This threading machine boasts a portable and lightweight design, facilitating effortless transport and convenient setup.

Designed for efficiency, the FLARE.3C features a self-contained oil system with adjustable flow control, ensuring optimal lubrication during operations. This feature enhances the machine’s longevity and overall performance.

With its powerful motor, portable build, and thoughtful oil system, the Macstroc FLARE.3C Threading Machine exemplifies a dedication to both functionality and user convenience, making it a reliable choice for various threading tasks.

Description

CAPACITY
Pipe: 1/8” -3”(3MM-80MM)
Bolt: 12MM-45MM
SPECIFICATIONS:
Motor: 1500W universal, 50/60Hz
Switch: Heavy-duty rotary Forward/off/reverse and integral
foot switch.
Spindle Speed: 32 RPM.
Front Chuck: Hammer type with replaceable rocker action
jaw inserts.
Rear Centering Device: Cam action.
Oiling System: Through the die head, with integral oil
reservoir.
Pump: Self-priming constant flow, gerotor pump.
STANDARD SUPPLY
Model FLARE.3C Threading Machine. (110 or 220V )
Self-opening die head-SDH15A 1/2-2”(BSPT or NPT )
Self-opening die head-SDH28 2-1/2-3”(BSPT or NPT )
1/2”-3/4” universal HSS dies set. (BSPT or NPT)
1”-2” universal HSS dies set. (BSPT or NPT)
2-1/2”-3” universal HSS dies set. (BSPT or NPT)
Cutter-MHC2030 : Capacity: 1/4”-3”(6mm-80mm) pipe
Reamer-MHR1008 : Positive-locking, 5-flute cone,
righthand 1/4”-3”(6mm-80mm).
*1 Gallon ‘Power Fluid PF-9835’ cutting oil.
Supplied with MFS642 foot switch, MH6511 folding wheel
*May not be supplied to certain countries
