Description
TECHNICAL DATA
|
Annular cutting |
Ø 12 – 120 mm |
|
Twist drilling |
Ø 38mm |
|
Countersinking |
Ø 10 – 120 mm |
|
Tapping |
M3-M42 |
|
Length |
440 mm |
|
Width |
230 mm |
|
Height |
660 – 750 mm |
|
Stroke |
210 mm |
|
Magnet (l x w x h) |
330 x 110 x 60 mm |
|
Magnetic force |
2400KG |
|
Motor power |
1800 W / 2050 W |
|
Speed (no load) |
82/180/245/535 RPM |
|
Spindle (Weldon) |
MT-4 / MT-3 [19,05 /31.75mm] |
|
Voltage |
110 – 120 V / 60 Hz 220 – 240 V /50-60 Hz |
|
Weight |
33 kgs |
